NORAC UC4.5-BC Quick Guide User Manual

Page 15

 The control panel will automatically move the booms to detect and assign the sensors to

the correct locations.

 Release the

button to continue.

Boom Geometry Tuning:

 Exit the cab and manually push either boom tip down 1 – 3 feet (30 – 90 cm) for a moment

and then let go.

 Do not walk near the sensors when approaching the boom. Stay at least 3 feet from the

sensor so as not to induce a measurement error.

Note: This step may not be applicable for all sprayer types.

Hydraulic Tuning:

 Hold the

button to continue the hydraulic tuning. If

is released before "Done" is

displayed, simply press and hold again to continue the procedure.

 The panel will display various messages as it is working. The messages are displayed for

informational purposes only.

 Release the

button, the hydraulic tuning is complete.

Done

“Done”

Until

Auto

Hold

& let go

ground

near to

boom tip

push

Exit Cab

Switch

Release
