8.3 Hydraulic Plumbing
From this point on in the installation the booms will be inoperative until the
hydraulics are fully installed.
Ensure there are no other orifices present in the circuit between the NORAC
valve block and the boom cylinders.
1. After the NORAC valves are mounted, the hydraulic hoses and fittings can be plumbed.
2. The plumbing for the hydraulic circuit is shown schematically in Figure 3.
3. Disconnect the “raise” lines from the sprayer valve block.
4. Install the 6FJXR-6MJT fittings (F02) onto the “raise” line ports.
5. Connect the “raise” lines and hoses H01 to the tees (F02).
6. Connect hoses H01 to the “B” ports of the NORAC valve block.
7. Disconnect the existing tank (“T”) and pressure (“P”) lines from the sprayer valve block.
8. Install the 8FJXR-8MJT fittings (F03) onto the open ports. Reconnect the existing hoses to
the respective tees.
9. Connect hoses H02 between the tees (F03) and the NORAC pressure and tank ports.
