MIDI Solutions Dual Footswitch Controller User Manual
Page 10

10
SYSTEM EXCLUSIVE
NOTE-ON FILTER
To program the Dual Footswitch Controller to send out a System Exclusive message when a footswitch is depressed,
send it the following System Exclusive Programming commands:
followed by
where
is the System Exclusive message the F8 is being programmed to send
All bytes must be in Hexadecimal format (see hexadecimal conversion table at end)
= Footswitch Input (00 for Fsw1 ... 01 for Fsw2)
To program the Dual Footswitch Controller to send out a System Exclusive message when a footswitch is released,
send it the following System Exclusive Programming commands:
followed by
where
is the System Exclusive message the F8 is being programmed to send
All bytes must be in Hexadecimal format (see hexadecimal conversion table at end)
= Footswitch Input (00 for Fsw1 ... 01 for Fsw2)
To program the Dual Footswitch Controller to send out the MIDI Machine Control
command (F0 7F 7F 06 02 F7)
when Fsw1 is depressed, and the MIDI Machine Control
command (F0 7F 7F 06 01 F7) when Fsw1 is released,
send the Dual Footswitch Controller the following System Exclusive Programming commands:
F0 00 00 50 14 06
F7 followed by
F0 00 00 50 14 06
F7 followed by
To program the Dual Footswitch Controller to filter Note-On messages on a selected MIDI channel when a footswitch
is depressed, send it the following System Exclusive programming command:
= Footswitch Input (00 for Fsw1 ... 01 for Fsw2)
= MIDI channel (see MIDI channel table at end)
=
: Send All-Notes-Off on depression of footswitch,
do not send All-Notes-Off on depression
To start filtering Note-On messages depress the footswitch (the All-Notes-Off message is sent out at this time), to
stop filtering release the footswitch.
F0 00 00 50 14 06 ii 01 F7
F0 ... F7
F0 ... F7
(max. 20 byes)
ii
F0 00 00 50 14 06 ii 00 F7
F0 ... F7
F0 ... F7
(max. 20 byes)
ii
Example
00 01
F0 7F 7F 06 02 F7
00 00
F0 7F 7F 06 01 F7
F0 00 00 50 14 0C ii cc aa F7
ii
cc
aa
01
aa = 00:
Play
Stop
