MicW M216 User Manual
Page 2
1. INTRODUCTION
Welcome to use
Mic
W
series professional microphones!
Mic
W
E216 has outstanding characteristics that make the microphone a valuable tool
in the studio, measurement and on the stage.
2. SAFETY INSTRUCTION
It is important to read all safety precautions and operating instructions before
attempting to operate the unit. Keep all safety precautions and operating instructions
for future reference.
Warning:
Condenser microphones are extremely moisture-sensitive. Never use your
microphone in close proximity to water (e.g. bath tubs, wash basins, sinks, washing
machines, pools, etc.). When doing voice recordings, always use the enclosed
windscreen to safely protect the capsule from moisture.
Please don’t touch the vibration parts especially the diaphragm behind the protection
grid. Don’t move the capsule when it is in operation. Take care not to drop your
microphone as this can lead to severe damage.
Mic
W
assumes no liability for any
damage caused by the user.
After each use, place it back into its protective casing. Then, lay the small bag
containing the moisture-absorbing crystals on top of the microphone head.
3. POWER SUPPLY
Phantom power (+48 V) is required to operate your microphone. We assume no
liability for damage caused to your E216 through defective phantom power. Before
activating phantom power, mute your playback system and connect the E216 to the
microphone input of your mixing console. After activating phantom power, the E216
requires several seconds to stabilize itself.
4. APPLICATIONS
The
Mic
W
E216 is a state-of-the-art stereo kit. Therefore, it is particularly well-suited for
stereo recordings. Regardless of whether you are milking an entire ensemble or a single
sound source (e.g. drums, piano or background
MICROPHONE E216/E216-Pair/M216
Capsule diameter
12.7 mm
Polar pattern
Omni
Sensitivity (±2dB)
32mv/Pa; -30 dB re. 1v/Pa
Frequency Response
20 Hz ~ 20kHz
Power Supply
48 V Phantom power
Total harmonic distortion
(THD)
＜1% up to 135 dB SPL peak
Thermal Noise
＜23 dBA
Output impedance
＜75 Ohm
Length
155mm
weight
155g
Connector
3-pin XLR
8. SPECIFICATIONS:
9. Contents in the case
E216/E216-Pair/M216 microphone(s);
Wind screen;
User’s manual..
Polar Pattern
