Of course, you can use Mic W
E418-pair that feature two matched E418
microphones as well. Each pair is guaranteed to the sensitivity match within 0.5
dB and phase match within 5°.
5. MICROPHONE INSTALLATION
First screw a clamp onto the stand before attaching the microphone itself.
6. AUDIO CONNECTION
To connect the E418 to your equipment, use a balanced XLR microphone cable
with the following pin assignment: Pin 1 = shielding, pin 2 = +, pin 3 = -. Since all
contact points of the E418 are gold-plated, your microphone cable should feature
gold-plated connectors, if possible.
7. DIRECTIONAL CHARACTERISTIC
The microphone features a capsule with Omni pickup pattern. Microphones with
this polar pattern are most sensitive to sound coming from in each angle of the
microphone.
Polar pattern
Polar Pattern
E418/E418-Pair Frequency Response
