MicW E418-Pair User Manual
Page 2
1. INTRODUCTION
Welcome to use
Mic
W
series professional microphones!
Mic
W
E418 has outstanding characteristics that make the microphone a valuable
tool in the studio, measurement and on the stage.
2. SAFETY INSTRUCTION
It is important to read all safety precautions and operating instructions before
attempting to operate the unit. Keep all safety precautions and operating
instructions for future reference.
Warning:
Condenser microphones are extremely moisture-sensitive. Never use your
microphone in close proximity to water (e.g. bath tubs, wash basins, sinks,
washing machines, pools, etc.). When doing voice recordings, always use the
enclosed windscreen to safely protect the capsule from moisture.
Please don’t touch the vibration parts especially the diaphragm behind the
protection grid. Don’t move the capsule when it is in operation. Take care not to
drop your microphone as this can lead to severe damage.
Mic
W
assumes no
liability for any damage caused by the user.
After each use, place it back into its protective casing. Then, lay the small bag
containing the moisture-absorbing crystals on top of the microphone head.
3. POWER SUPPLY
Phantom power (+48 V) is required to operate your microphone. We assume no
liability for damage caused to your E418 through defective phantom power.
Before activating phantom power, mute your playback system and connect the
E418 to the microphone input of your mixing console. After activating phantom
power, the E418 requires several seconds to stabilize itself.
4. APPLICATIONS
The
Mic
W
E418 is a state-of-the-art stereo kit. Therefore, it is particularly
well-suited for stereo recordings. Regardless of whether you are miking an entire
ensemble or a single sound source (e.g. drums, piano or background vocals), this
microphone lets you achieve outstanding spatial impressions in every recording
session.
MICROPHONE E418/E418-Pair
Capsule diameter
7 mm
Polar pattern
Omni
Sensitivity (±2dB)
10mv/Pa; -40 dB re. 1v/Pa
Frequency Response
20 Hz ~ 20kHz
Power Supply
48 V Phantom power
Total harmonic distortion
(THD)
＜1% up to 135 dB SPL peak
Thermal Noise
＜26 dBA
Output impedance
＜75 Ohm
Length
145mm
weight
135g
Connector
3-pin XLR
8. SPECIFICATIONS:
9. Contents in the case
E418/E418-Pair/M418
microphone(s);
Wind screen;
User’s manual..
Polar Pattern
