MCS 500 Automatic Dialer Installation Checklist
Topic
Item Page
System Installation
___
Physical System Installation 8
___ Connecting Electrical Power 9
___ Telephone Line Installation 10
___ Battery Activation 8
I/O Card Installation
___ Digital Input Card Installation 13
___ Analog Input Card Installation 13
___ Digital Output Card Installation 14
___ Printer Output Card Installation 15
___ Apply Power and Initialize System 11
___ I/O Card Selection and Initialization 11-12
___ Telephone and I/O Data Initialization 11
System Programming
___
System Level Data 16-19
___ Power Fault Channel Data 19-22
___ Telephone Directory Numbers 22-23
___ Telephone List Programming 23
___ Setting the System’s Real Time Clock 24
I/O Channel Programming
___
Digital Input Card Programming 25-28
___ Analog Input Card Programming 28-31
___ Digital Output Card Programming 31-33
___ Printer Output Card Programming 33-34
Verification of Operation
___
Test Local Operation 35-36
___ Putting the System into the Run Mode 37-38
___ Verify Remote Operation 39-41
