MICROTEL

DialStat

TM


24

APPENDICES

APPENDIX A:

Technical Specifications


A.1 Communications

Phone Interface:

ACTA ID:

7AAAD00BDS65616

For connection to PSTN or Cellular network via
Cellular Interface.

Ringer Equivalence Number: 0.0B

LED Indicators:

Dialer Active/Ring Detect/Call Progress

Local Telephone Off-hook/Ready to program

Fault/Normal status for each input channel

Low-power/battery operation indication

AC Power/Charging


Dialing Capacity:

8 Phone Numbers, 30 Digits Each

Tone or Pulse Dial

Special Sequences for Selection of Pulse/Tone,
Pause, Pagers, Auto-Acknowledging Alarms.


Call Progress Detection

Dial Tone Detect

Busy

Detect

Ring Back/No Answer Detection


Answer Delay:

1-99 Rings (Call Back Acknowledge)


A.2

Electrical

Input Power:

Plug in Wall Power Supply, 120 VAC to 12 VDC

UL/CSA

approved.

or 12-20VDC @ 0.5 Amp

Solar Power Interface Compatible

On/Off

Switch

Internal Battery-charging circuit

AC Power/Battery Charging Indicator

Resettable Internal Fuse

Optional: Micromax Surge Suppressor


Battery Operational:

Rechargeable 6-AA cells NiCad Battery Pack

(24 hour standby, 6 hour active calling, typical)
