Longshine LCS-WR5-2214-A - Manual (Page 39)

34
Port forwarding
The Port Forwarding allows you to re-direct a particular range of service
port numbers (from the Internet/WAN Ports) to a particular LAN IP
address. It helps you to host some servers behind the router NAT firewall.
Configuration
1. Click the check box of “Enable port forwarding” to
enable the function.
2. Enter the specific IP address (EX 10.10.10.10),
Protocol (UDP/TCP), Port range (EX 25-110), and
comment (EX. E-Mail)
STEPS
3. To Delete the IP address on the table, Click the
check box in the select item and click the “Delete
Selected”. If you want to delete all Entries on the
table, click “Delete All” to remove all of them.
Click at the bottom of the screen to save the above configurations.
