3
1.2 Physical Diagram
z PC LED Indicators:
RED LED indicates that the 2-port USB Cable KVM Switch is switched to the
corresponding PC.
z PC connection LED Indicators:
GREEN LED indicates the status of PC connection.
1.3 Package Contents
The product you purchased should contain the following equipment and
accessories:
1. One 2-port USB Cable KVM Switch with Audio.
2. User Manual.
USB Keyboard
USB Mouse
VGA Output
PC 1 LED Indicators (Red)
MIC Jack
PC connection 1 LED Indicators (Green)
PC connection 2 LED Indicators (Green)
PC 2 LED Indicators (Red)
Speaker Jack
PC Selection Push Button
PC Selection Push Button
