1000Base-T to 1000Base-SX/LX Converter
14
Installation
Note: The devices attached to each port can be
connected and operating in any sequence, but
the factory recommended procedure is as follows:
1. Converter power OFF
2. Set DIP switch(es) (ON or OFF)
3. Power ON the converter
4. Connect Fibre links
5. Connect Copper links
Desktop Installation
Follow the instructions listed below to install the Converter
onto a desktop location.
1. Locate the Converter in a clean, flat and safe position
that has easy access to AC power.
2. Affix the four (4) self-adhesive rubber pads to the
underside of the Converter.
3. Apply AC power to the Converter. (The green PWR
LED on the rear panel should light).
4. Connect cables from the network partner devices to
the ports on the front panel. (The green LNK LED on
the front panel associated with the port should light).
