Page 24, Pilot controller — type ddd, 15-75 range – Leslie Controls Pilot Controller User Manual

Page 24

background image

Page 24

REF PRESSURE

PIPE CONNECTION

1/4” PIPE THREAD

REF PRESSURE

PIPE CONNECTION

3/8” PIPE THREAD

1/4” LESLIE SELF-CLEANING STRAINER

1/4” APPLICABLE LESLIE

PRESSURE REDUCING VALVE

MAXIMUM STATIC PRESSURE 300 PSIG.

RATIOS

SPECIFY WHEN ORDERING

1.1:1
1.2:1
1.3:1

1.4:1
1.5:1
1.6:1

2:1

3:1

SUPERSEDES DRAWING NO. CP-14620 F, ALT. 3

PILOT CONTROLLER — TYPE DDD, 15-75 RANGE
