Crown Boiler 32 - Manual (Page 6)

6
Table 1B: Specifications
4
Wat er
(MBH) (MBH) (Sq. ft) (MBH) (MBH) (Gal) (Gal)
32-475W(S)N 6 475 380 1188 285 330 80-1/2 28.58 39.80 11.4
32-570W(S)N 7 570 456 1425 342 397 80-1/2 32.65 45.47 13.6
32-665W(S)N 8 665 532 1663 399 463 80-1/2 36.72 51.14 15.9
32-760W(S)N 9 760 608 1900 456 529 80-1/2 40.79 56.81 18.2
32-855W(S)N 10 855 684 2138 513 595 80-1/2 44.86 62.48 20.4
32-950W(S)N 11 950 760 2376 570 661 80-1/2 48.93 68.15 22.7
32-1045W(S)N 12 1045 836 2613 627 727 80-1/2 53.00 73.82 25.0
32-1140W(S)N 13 1140 912 2851 684 793 80-1/2 57.07 79.49 27.2
32-1235W(S)N 14 1235 988 3088 741 859 80-1/2 61.14 85.16 29.5
32-1330W(S)N 15 1330 1064 3326 798 925 80-1/2 65.21 90.83 31.8
32-1425W(S)N 16 1425 1140 3563 855 991 80-1/2 69.28 96.50 34.1
32-1520W(S)N 17 1520 1216 3801 912 1057 80-1/2 73.35 102.17 36.3
32-1615W(S)N 18 1615 1292 4050 972 1123 80-1/2 77.42 107.84 38.6
32-1710W(S)N 19 1710 1368 4312 1035 1190 80-1/2 81.49 113.51 40.9
32-1805W(S)N 20 1805 1444 4575 1098 1256 80-1/2 85.56 119.18 43.1
32-1900W(S)N 21 1900 1520 4839 1161 1322 80-1/2 89.63 124.85 45.4
32-1995W(S)N 22 1995 1596 5102 1225 1388 80-1/2 93.70 130.52 47.7
32-2090W(S)N 23 2090 1672 5366 1288 1454 80-1/2 97.77 136.19 49.9
32-2185W(S)N 24 2185 1748 5628 1351 1520 80-1/2 101.84 141.86 52.2
32-2280W(S)N 25 2280 1824 5890 1414 1586 80-1/2 105.91 147.53 54.5
32-2375W(S)N 26 2375 1900 6143 1474 1652 80-1/2 109.98 153.20 56.8
32-2470W(S)N 27 2470 1976 6392 1534 1718 80-1/2 114.05 158.87 59.0
32-2565W(S)N 28 2565 2052 6638 1593 1784 80-1/2 118.12 164.54 61.3
32-2660W(S)N 29 2660 2128 6884 1652 1850 80-1/2 122.19 170.21 63.6
32-2755W(S)N 30 2755 2204 7130 1711 1917 80-1/2 126.26 175.88 65.8
32-2850W(S)N 31 2850 2280 7376 1770 1983 80-1/2 130.33 181.55 68.1
INPUT
3. Rat ings Based on 33,475 Btuh Per Boiler Horsepower
I=B=R NET RAT ING
Steam
WAT ER
VOL.
2
BHP
OUT PUT
3
2. Water Volume T ot al (Wat er Boiler).
1. Water Volume T ot al T o Normal Wat er Line (St eam Boiler).
BASIC BOILER
MODEL
NUMBER
OF
SECT IONS
WAT ER
VOL.
1
NAT URAL GAS ONLY
HEAT ING
CAPACIT Y
Combust ion
Effy. %
