VT640300, VT640400, VT640600 Replacement Parts List
For replacement parts or technical assistance,
call 1-800-543-6400
Please provide following information:
- Model number
- Serial number (if any)
- Part description and number as shown in parts list
www.chpower.com
1 Tank AR062200AV AR062300AV AR062300AV 1
2 Drain valve D-1403 D-1403 D-1403 1
3 Rubber foot s s s 2
4 Foot Bolt s s s 2
5 Washer s s s 12
6 Nut s s s 2
7 10 inch Wheel n n n 2
8 Axle bolt n n n 2
9 Washer n n n 2
10 Hex nut n n n 2
11 Handle l l l 1
12 Handle screw l l l 2
13 Motor cord EC015100AV EC015100AV EC015100AV 1
14 Power cord and plug assembly EC015000AV EC014900AV EC015000AV 1
15 Check valve VT911300AV VT911300AV VT911300AV 1
16 Regulator RE206901AV RE206901AV RE206901AV 1
17 Gauge (back mount) GA016718AV GA016718AV GA016718AV 1
18 1/4 inch Nipple H H H 2
19 Gauge GA016709AV GA016709AV GA016709AV 1
20 Pressure switch (includes Unloader valve) CW217400AV CW217400AV CW217400AV 1
21 Unloader valve CW212400AV CW212400AV CW212400AV 1
22 ASME Safety valve V-215105AV V-215105AV V-215105AV 1
23 Nut (pressure switch end) t t t 1
24 Ferrule (pressure switch end) t t t 1
25 Nut (check valve end) t t t 1
26 Ferrule (check valve end) t t t 1
27 Unloader tube t t t 1
28 Exhaust tube VT910700AV VT910700AV VT910700AV 1
29 Elbow fitting ST085900AV ST085900AV ST085900AV 1
30 u Pump VT480000KB VT470000KB VT480000KB 1
31 Oil drain extension ST083800AV ST083800AV ST083800AV 1
32 Oil drain cap ST150100AV ST150100AV ST150100AV 1
33 Pump mounting bolt ST016000AV ST016000AV ST016000AV 4
34 5/16 inch - 18 Locknut H H H 8
35 Electric motor (includes Motor key) MC015502SJ MC015403SJ MC015502SJ 1
36 Motor key KE000903AV KE000903AV KE000903AV 1
37 Motor mounting bolt H H H 4
38 Pulley PU015200AV PU012600AV PU015200AV 1
39 1/4 - 20 x 1/2 Setscrew H H H 1
40 Flywheel (includes 3/8 - 16 x 3/4 Setscrew) PU015900AJ PU015900AJ PU015900AJ 1
41 3/8 - 16 x 3/4 Setscrew H H H 1
42 Belt BT020400AV BT020400AV BT020400AV 1
43 Belt guard (back) 1
44 Belt guard (front) 1
45 Hang plate 1
46 Hang plate screw 1
47 Belt guard screw 5
48 Washer 5
49 Belt guard locker 6
50 Power cord strain relief CW212900AV CW212900AV CW212900AV 1
51 Motor cord strain relief CW212800AV CW212800AV CW212800AV 1
REPAIR PARTS KITS
s
Rubber foot kit HL021300AV HL021300AV HL021300AV
n Wheel Kit VT910600AV VT910600AV VT910600AV
l Handle Kit VT910800AV VT910800AV VT910800AV
t Unloader tube assembly VT911500AV VT911500AV VT911500AV
Belt guard assembly VT911000AV VT911000AV VT911000AV
Belt guard hardware kit VT911100AV VT911100AV VT911100AV
H Standard hardware item - available at your local hardware store
u See compressor nameplate for exact model number when ordering pump repair parts.
Ref. Part Number for Models:
No. Description VT640300 VT640400 VT640600 Qty.
Replacement Parts List
Address parts correspondence to:
Campbell Hausfeld
Attn: Customer Service
100 Production Drive
Harrison, OH 45030 U.S.A.
