LAARS Heating Systems Company
Figure 2.
1. FIT FRONT PANEL (1)
2. ATTACH SIDE PANELS (2) AND (3) TO
BOTTOM OF BOILER AND FRONT
PANEL
3. FIX REAR PANELS (4) AND (5) TO SIDE
PANELS
4. FIT TOP PANEL (6)
Relief Valve
Bolted Coil Flange for easy
re-tightening - no Studs to
break
Aquastat Relay
Domestic Water Connections
Removable Flue Cover for
easy tube cleaning
CO
2
and Draft Test Plug
Flame Observation Glass
CO
2
and Draft Test Plug
Flame Retention Oil Burner
Glass fiber Rope for positive
gas tight seal
Flame Reverse Combustion
Vent Pipe
Hydronic Supply
with dip tube
Heavy gauge Enamelled Jacket
Tankless Coil 4 gal./min. in
hottest zone
Horizontal Fire Tube Design
Stainless Steel Flue Gas
Tubulators for optimum heat
transfer and highest efficiency
Flue Cleaning Ports
Flue Collector external fixing
no bolt corrosion
Extra Heavy Duty Insulation
for low stand-by losses
Hydronic Return
Sludge Clean-out Socket
SIDE PANEL TO FRONT
PANEL FIXING
OUT OF
PRODUCTION
