Mighty Stack Page 29
CONTROL PANEL COMPONENTS See Figure 13
1 Switch, Pressure, Diaphragm, SPST E0255500 E0255500 E0255500
2 Switch, Pressure, Diaphragm, SPDT E0240900 E0240900 E0240900
3 Switch, Limit, High Temperature, Volume Water E2324200 E2324200 E2324200
4 Transformer, 24, 120V, 50VAC E0180500 E0180500 E0180500
5 Ignition Control, Hot Service Ignition E0253400 E0253400 E0253400
6 SPDT Toggle Switch E0109200 E0109200 E0109200
7 Tray, Control Panel 20L7002 30L7002 40L7002
8 Relay, Time Delay, 24 Vac, Delay On Break,
Adjustable
E2077700 E2077700 E2077700
9 Ignition Control, HSI, Fenwal E0253400 E0253400 E0253400
Switch, Rocker, 10A, 250 VAC 1/2 HP, 15A, 125
VAC 1/2 Hp
E2322700 E2322700 E2322700
Switch, Temperature, Manual Reset, 250°,
SPST, Trip-Free
E2103200 – –
10 DPDT Toggle Switch, 15 Amps, 3/4 HP E2056300 E2056300 E2056300
11 Block, Terminal, Double Row, 16-Position E2327500 E2327500 E2327500
12 Jumper, Terminal Block E0102000 E0102000 E0102000
13 Label, Terminal, Control Contacts H2339100 H2339100 H2339100
14 Harness, Main E2337800 E2337800 E2337800
15 Harness, Wire, On/Off, Switch E2337900 E2337900 E2337900
PUMP ASSEMBLY COMPONENTS See Figure 14
1 Circulator Pump Assembly A2112200 A2112200 A2112200
Alternate Soft Water Pump A2112212 A2112212 A2112212
2 Union, 1-1/4" C x C 36-518 36-518 –
Union, 1-1/2" Solder Joint, Copper/Brass Nut – – P2020100
3 Adapter, Copper, C x M, 1-1/4" x 1-1/2" NPT P2049500 P2049500 –
(6)
Adapter, 1-1/2" Male NPT x 1-1/2" soc, Copper – – P2019700
4 Water Flow Switch, Outdoor E0013000 E0013000 E0013000
5 Tee, 1-1/4" soc x 1" sox x 1-1/4" soc, Copper P2079700 P2079700 –
Tee, 1-1/2" soc x 1" soc x 1-1/2" spc – – P2079600
6 Adapter, Copper, 1-1/4" to 1" NPT P2079800 P2079800 P2079800
7 Flow Switch Paddle E2105400 E2105400 E2105400
8 Elbow, 1-1/2" NPT x 1-1/2" CU, Cast Brass – – P2079300
Item Description Size 199 Size 300 Size 399
