Kuzma AIR LINE 130401 User Manual
Page 7
Remove the small plastic cap from the metal input tube at the head of compressor, which is on
the side wall marked “oil”. Fig. 4.
Fix the nozzle with clear tube onto the oil bottle.
Put the tube into the metal tube, gently squeeze all the oil into the compressor. Wipe any
spillage of oil. Cover the tube with plastic cap.
Fig.3 Rear of the compressor
Fig.4 Oil filling from side of the compressor Fig.5. Double drain PVC bottle system
7
Air intake filter
Oil level bubble
