General Setup
Press the CURSOR buttons to select "TV DISPLAY" and then press the cursor buttons. The TV set screen displays:
Press the SETUP button to exit the function setup menu. You have made a successful setup.
Press the CURSOR button to select your desired setting and then press the SELECT button.
To select the "GENERAL SETUP" menu then press the SETUP button.
Page 19
TV Display
Repeat the same basic procedure for all other menu options :
OSD Language default : ENGLISH
Video Output default : Y Cb Cr
Screen Saver Factory default : ON
OPERATION
NORMAL/PS
NORMAL/LB
WIDE
Note :
The playback effects are contingent upon the disc’s recording aspect ratio. Some discs may not be played according to your selected aspect ratio.
When wanting to use the RGB output from the scart socket - please select this option from within the Video Output menu - please ensure you have
a fully wired scart lead and have selected the RGB input on your television.
