MODEL DS650™ X
ELECTRICAL
Make Denso
Magneto generator
Type 290 W @ 6000 RPM
Ignition type
Breakerless high voltage condenser ignition
system with electronic spark advance
Ignition timing Not adjustable
Engine RPM limiter 7900 RPM (any gear in forward)
Make NGK
Type DR 8 EA Spark plug
Gap 0.6 to 0.7 mm (.024 to .027 in)
Number of spark plug 2
Type Dry type battery.
Battery
Volt 12 volts, 13 Ah
Instrument Tachometer
Starting system
Electric start. Start in any gear (with
clutch applied or on NEUTRAL)
Headlamp bulb 2 x 30 W
Taillight and brake light bulb 8/27 W, 1157
Auxiliary headlight 2 x 35 W, H3
Fan 15 A
Auxiliary headlight 15 A Fuses
Charging system 25 A
DRIVE TRAIN
Rear axle Chain driven/solid axle
Turning radius 3.16 m (10 ft)
SUSPENSION
Independent suspension — single A-arm,
Type
2 shock absorbers (oil/gas) Front
Travel 305 mm (12 in)
Rigid swing-arm
Type
1 shock absorber (oil/gas) Rear
Travel 279 mm (11 in)
88
