A15E0KY
1
2
TYPICAL
1. Fuse
2. Check if melted
Bulb Replacement
Always check light operation after re-
placement.
Headlamp
If the headlamp bulb is burnt:
– Remove front fascia.
– Remove rubber boot.
V02G1MY
– Push and turn counterclockwise
bulb socket ring then remove the
bulb.
V02G1NY
– Detach bulb and replace.
V02G1OY
Properly reinstall removed parts in the
reverse order of their removal.
NOTE: Align the bulb socket tab with
the notch in the headlamp housing.
V02G1PY
1
1. Bulb socket tab
Taillight
Unscrew lens screws to expose bulb.
_____________________
105
