Cadillac 2004 Escalade ESV User Manual
Page 422
Fuses
Usage
RR HVAC
Rear Climate Control
AUX PWR
Auxiliary Power Outlet —
Console
IGN 1
Ignition Relay
PCM 1
Powertrain Control Module
ETC/ECM
Electronic Throttle Control,
Electronic Brake Controller
INJ 1
Ignition Coil, Fuel
Injectors--Bank 1
INJ 2
Ignition Coil, Fuel
Injectors--Bank 2
IGN E
Instrument Panel Cluster, Air
Conditioning Relay, Turn
Signal/Hazard Switch, Starter
Relay
RTD
Ride Control
TRL B/U
Backup Lamps Trailer Wiring
PCM B
Powertrain Control Module,
Fuel Pump
F/PMP
Fuel Pump (Relay)
O2A
Oxygen Sensors
Fuses
Usage
B/U LP
Back-up Lamps, Automatic
Transmission Shift Lock
Control System
RR DEFOG
Rear Window Defogger
HDLP-HI
Headlamp High Beam Relay
PRIME
Not Used
O2B
Oxygen Sensors
SIR
Supplemental Inflatable
Restraint System
FRT PARK
Front Parking Lamps,
Sidemarker Lamps
DRL
Daytime Running Lamps
(Relay)
SEO IGN
Rear Defog Relay
TBC IGN1
Truck Body Controller Ignition
HI HDLP-LT
High Beam Headlamp-Left
LH HID
Left Hand High Intensity
Discharge Lamps
DRL
Daytime Running Lamps
IPC/DIC
Instrument Panel Cluster/
Driver Information Center
5-116
