XK100 Keyboard Amplifier
XK100 TECHNICAL SPECIFICATIONS:
Maximum Signal Accepted Ch. 1 High Z: 10 volts peak to peak; Low Z: 15 volts peak to peak
Ch.’s 2, 3 and 4: 10 volts peak to peak
Input Power Requirements 115 VAC, 60Hz, 110VA
100/110VAC, 50/60Hz, 110VA
230VAC, 50/60Hz, 110VA
Nominal Input Impedance Ch. 1 High Z: 10k ohms; Low Z: 600 ohms
Ch’s 2, 3 and 4: 24k ohms
Gain Ch. 1: High Z: 64dB; Low Z: 70dB; Ch. 2: 57dB;
Ch. 3: 57dB; Ch. 4: 57dB
Output Power Rating 100 watts @ 5% THD w/4 ohm load
Rotary EQ Range Channel 1: 15dB @ 100Hz, 23dB @ 10kHz
Master EQ ±14dB @ 100Hz, 330Hz, 1kHz, 4kHz and 10kHz
Line In/Line Out 1 volt RMS
Limiter Range 20dB, maximum distortion 1%
Speaker Size and Rating 15” Crate Custom Design w/2.5” voice coil and 56 oz. magnet
2 HF drivers
Cabinet Size and Weight 24.5” H x 21” W x 18.25” D, 69 lbs.
©2004 SLM ELECTRONICS, A DIVISION OF ST. LOUIS MUSIC, 1400 FERGUSON, ST. LOUIS, MO. U.S.A. 63133
P/N 47-362-02 • 111704
