4
I
H
1
Assemble the three casters (I ) to the bottom shelf (H) as shown.
Fig. 1
D
H
C
E
2
Assemble the left side panel (D) to the bottom shelf (H) using hard-
ware #1, #2, #3, and #4 (x2) to Affix the front part of the left
side panel (D) to the bottom shelf (H).
Affix the right side panel (E) to the bottom shelf (H) using hardware
#1, #2, #3, and #4 (x2). Place the front shelf (C) between two side
panels (D & E) as shown. Use hardware #5, #6, and #7 (x6) as
shown to connect together with both side panels.
Fig. 2
F
G
C
H
D
3
Affix the left and right back shelf ( F & G) to the bottom panel using
hardware #1, #2, #-3, and #4 (x2) as shown.
Then Affix each back shelf to the side shelf using hardware #5, #6,
and #7 (x6).
Fig. 3
