#1 – 1/4-20UNCx13Screw (6)
Hardware Pack List
No. Description Part Number Quantity
1 1/4-20UNCx13Screw 20120-13013-250 6
2 Ø7 Lock Washer 41400-07000-250 6
3 Ø7 Washer 40300-07000-250 6
4 1/4”-20UNC NUT 30220-13000-250 2
5 NO.10-24UNCx10 Screw 20124-10010-250 12
6 Ø5 Lock Washer 41400-05000-250 12
7 Ø5 Washer 40300-05000-250 12
8 Wrench G401-0071-0182 1
A S S E M B L Y I N S T R U C T I O N S
Before assembling the cart, read these instructions carefully.
Assemble the cart on a flat, clean surface.
Notes: Do not fully tighten all the nuts during this initial stage.
You may have extra hardware after assembly is complete.
• Hammer
• #3 Phillips ® screwdriver
• Slotted screwdriver
• Safety glasses
Tools Needed for Assembly
#4 – 1/4”-20UNC NUT (2)
#5 – NO.10-24UNCx10 Screw (12) #7 – Ø5 Washer (12)
#3 – Ø7 Washer (6) #2 – Ø7 Lock Washer (6)
#6 – Ø5 Lock Washer (12)
