9341 User Manual •••• (V 1.0) Page 17 of 22
Menu Item Format Description
DARS Locked / Unlocked
Status indicator for DARS
audio input
Reference Standard ############
Detected standard of
selected reference.
Settings Saved / Unsaved
This shows whether the
current settings have been
saved to a preset.
Menu Item Format Description
Analog Ch 1-8
Tone Generator 1-4
Source
(per channel)
Silence
Selects the source for the
AES outputs. Each AES
source can be chosen
separately.
Gain
(per channel)
Range (-400) - 400
Gain applied to AES
audio output.
Normal
AES Audio
Out Pairs 1-4
Phase
(per channel)
Invert
Inverts the phase of the
AES audio output.
Menu Item Format Description
Tone
Generator Tone Generator 1-4
Frequency
Range 50Hz –16KHz
Selects the frequency of
the tone generated.
Menu Item Format Description
Parameter Save Confirm
Saves the parameters as
preset.
Parameter Load Confirm
Loads parameters
previously saved.
Presets
Restart Parameters
to Factory Default
Confirm
Will load factory presets
and overwrite the save.
