33 105983
OWNER’S MANUAL
PARTS LIST
DIRECT-VENT FIREPLACE
CHDV34NA
CHDV34PA
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 31 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 104445-01 Top Outer Casing 1
2 105278-01 Outer Casing 1
3 105297-01 Bottom Outer Casing 1
4 104479-10BR Firebox Assembly 1
5 M11084-26 Screw, Hex 50
6 M11084-46 Screw, Hex 8
7 105394-01 Louver, Extruded 2
8 104443-01 Firebox Support, Right 1
9 104486-01 Firebox Support, Left 1
10 104482-01 Switch Bracket 1
11 104483-01 Floor Mounting Bracket 2
12 104491-01 Relief Cover 1
13 104518-01 Relief Cover Gasket 1
14 104527-01 Relief Spring 2
15 104528-01 Relief Washer 2
16 104537-01 Valve Bracket 1
17 104496-01 SIT Valve, Natural 1
104496-02 SIT Valve, Propane/LP 1
18 104497-01 SIT Pilot, Natural 1
104497-02 SIT Pilot, Propane/LP 1
19 104498-01 Thermocouple 1
20 104499-01 Thermopile 1
21 104500-01 Ignitor 1
22 104501-01 Ignitor Bracket 1
23 104502-01 Ignitor Screw 1
24 104503-01 Ignitor Wire 1
25 104504-01 Burner, Natural 1
104504-02 Burner, Propane/LP 1
26 104506-01 Orifice, Natural 1
104506-02 Orifice, Propane/LP 1
KEY
NO.
PART NUMBER DESCRIPTION QTY.
27 104507-01 Brass Elbow 1
28 104508-01 Brass Fitting 2
29 104509-01 Aluminum Tubing Assy 1
30 104510-01 Pilot Tubing Assy 1
31 104954-01 Screw 3
32 104963-01 Washer 3
33 104955-01 Nut 3
34 105457-01 Log Set
34-1 105772-01 Rear Log 1
34-2 105772-02 Front Log 1
34-3 105772-03 Left Log 1
34-4 105772-04 Right Log 1
35 M10908-2 Screw 6
36 M12461-73 Screw 3
37 H5C4-20B Bolt 2
38 NTC-4C Locknut 2
39 M12461-26 Screw 4
40 104555-02CJ Grate Assembly 1
41 105775-16 Glass Door Assy 1
42 104490-02CJ Baffle 1
43 105450-01CK Front Assembly 1
44 104615-02 Insulation 1
45 104313-01 Hinge, Pin - Left 1
46 104313-02 Hinge, Pin - Right 1
47 105325-01 Burner Baffle 1
48 105575-01 Wire Harness 1
PARTS AVAILABLE - NOT SHOWN
GA6060 Lava Rock 1
104529-01 Ember Material 1
