29
Fitting the Adjustable Feet
– The adjustable feet must be fitted to the base of the cooker before use.
– Rest the rear of the cooker an a piece of the polystyrene packaging exposing the base for the fitting of the feet.
– Fit the 4 legs by screwing them tight into the support base as shown in picture 33.
WARNING
When raising cooker to upright position always ensure two people carry out this manoeuvre
to prevent damage to the adjustable feet (fig. 34).
Fig. 32 Fig. 33
Assembling the Backguard
Before installing the cooker, assemble the
backguard “V” (fig. 31).
Please note that :
– The backguard “V” can be found packed at
the rear of the cooker.
– Before assembling remove any protective
film/adhesive tape.
– The backguard must be fixed to the cooktop
using the three supports “B” supplied with
the appliance (see fig. 31).
V
A
B
A
V
B
Fig. 31
