GETTING READY
23
Power Requirements
Your camera is powered by a rechargeable lithium ion bat-
tery (NP-20).
To load the battery
1. Pressing the battery cover on the side of the
camera, slide it in the direction indicated by
the arrow and then swing it open.
2. Align the arrow mark on the battery with the
arrow mark on the camera as shown in the il-
lustration, and slide the battery into the battery
compartment.
3. Swing the battery cover closed, and then slide
it in the direction indicated by the arrow while
pressing down on it.
IMPORTANT!
• Use only the special NP-20 rechargeable lithium ion
battery to power this camera. Use of any other type of
battery is not supported.
NOTE
• When removing the battery, open the battery cover
and tilt it towards the side. When the battery slides out
part way, pull it out by hand.
The battery is not charged when you purchase the cam-
era. You need to charge the battery before using the
camera for the first time.
Arrow marks
NP-20
