REV 3/28/2012
JAYPRO SPORTS
PVBWINCH
LIST OF MATERIALS
SYSTEM
PIECE NO. DESCRIPTION QTY.
1 WINCH FOR VB STANCHION 1
2 BUTTON HEAD SCREW, 3/8-16 x 1/2” 2
3 FLAT WASHER 3/8” 4
4 BUTTON HEAD CAP SCREW, 3/8-16 X 4-1/2” 1
5 BUTTON HEAD CAP SCREW 3/8-16 x 4’’ 1
6 ACORN NUT, 3/8-16 1
7 SOCKET HEAD CAP SCREW 1/4-20 x 3/4’’ 2
8 SOCKET HEAD CAP SCREW 1/4-20 x 1’’ 2
9 SOCKET HEAD CAP SCREW 1/4-20 x 4” 2
10 LOCK NUT 1/4-20 2
11 ACORN NUT 1/4-20 2
IMPORTANT INFORMATION
PERIODICALLY CHECK ALL FASTENERS. RETIGHTEN AS NECESSARY AND
REPLACE ANY MISSING PIECES. DO NOT ATTEMPT TO ADJUST THE NET
HEIGHT BY RAISING THE UPRIGHTS WHEN THE UNIT IS UNDER TENSION.
THIS MAY DAMAGE THE WINCH OR THE INTERNAL HEIGHT ADJUSTMENT
MECHANISM. FIRST, RELEASE THE NET TENSION, THEN RAISE THE UPRIGHTS TO
A NEW POSITION, RE-TENSION THE NET. ALWAYS USE THIS SYSTEM WITH THE
PROTECTIVE PADS PROPERLY IN POSITION.
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED: 9/16” BOX WRENCH OR ADJUSTABLE WRENCH (2)
7/32”
HEX WRENCH
3/16’’ HEX WRENCH
1) DETERMINE WHICH SYSTEM YOU HAVE AND SELECT THE APPROPRIATE
ASSEMBLY ILLUSTRATION. NOTE THAT THE WINCH IS ASSEMBLED
DIFFERENTLY FOR A 3 ½” OD OR A 3” OD UPRIGHT. SLIDE THE WINCH (1)
ONTO THE UPRIGHT FROM THE BOTTOM AND ALIGN WITH THE MOUNTING
HOLES AS INDICATED. THE WINCH BOX MUST BE OUTSIDE THE COURT
AREA AND IN LINE WITH THE PULLEY ASSEMBLY. FASTEN WINCH USING
THE APPROPRIATE HARDWARE AS SHOWN AND TIGHTEN FULLY.
2) FEED THE LEADER STRAP UP AND OVER THE PULLEY ASSEMBLY. TAKE UP
A FEW TURNS OF THE STRAP ON THE WINCH. CONTINUE TO ASSEMBLE
THE REMAINING SYSTEM COMPONENTS AS SHOWN ON THE OTHER
ILLUSTRATIONS INCLUDED WITH YOUR SYSTEM.
