JAYPRO SPORTS

GALVANIZED TENNIS POSTS, TPGS-35

LIST OF MATERIALS

PIECE NO. PART

NO. DESCRIPTION

QTY.

1

RT-5

RATCHET WHEEL WITH HANDLE

1

2

HS324

SET SCREW 3/8”-16 x ½”

4

3

AF71A

PULLEY CAP

2

4

HN2949

EYENUT 3/8”-16

2

5

05319

HEX HEAD SCREW ¼”-20 x 2”

2

6

HN256

LOCK NUT ¼”-20

2

7

AF737

PULLEY

2

8

TPGS351

UPRIGHT

2

12

HB852

U-BOLT 3/8”-16 x 4”

1

13

HN265

LOCK NUT 3/8”-16

1

14

HW337

LOCK WASHER 3/8”

2

15

HS856

HEX HEAD BOLT 3/8”-16 x 4”

4

16

HN1230

THIN LOCK NUT ½”-13

2

17

HW2047

FLAT WASHER 3/8”

3
