Jaypro Sports SGP-400 - Manual (Page 2)

REV-C 5/13
JAYPRO SPORTS
OFFICIAL PORTABLE SOCCER GOAL, SGP-400
LIST OF MATERIALS FOR TWO GOALS
ITEM #. PART NO. DESCRIPTION QTY
1 SG-400USR RIGHT UPRIGHT WELDMENT 2
2 SG-400USL LEFT UPRIGHT WELDMENT 2
3 SG-001PC 4" SOCCER CROSSBAR, x 280" L 2
4 SG-760RX 1.90" REAR CROSSBAR, x 288" L 2
5 SGP-760BS BACKSTAY FOR SGP-760 & SGP-400 4
6 SG-760C 1.90" BACKSTAY CONNECTOR, x 96 5/8" L 4
7 SR5418 1.90" CARRIAGE PIPE CLAMP 8
8 HB5038 3/8"-16 x 2 1/2" CARRIAGE BOLT 8
9 HS1616 3/8"-16 x 2 3/4" HEX HEAD CAP SCREW, ZP 8
10 HS5225 3/8"-16 x 1 1/4" BUTTON HD. CAP SCREW, SS 12
11 HW2047 3/8" SAE FLAT WASHER, ZP 28
12 HN1230 3/8"-16 THIN NYLON LOCK NUT NTE, ZP 16
13 HW2152
3/8” MEDIUM SPLIT LOCK WASHER, SS
12
14 HW2151
3/8” FLT SAE, SS
12
15 ENC-824 EASY TRACK NET CLIP 100/PKG 2
INSTALLATION AND USE CONSIDERATIONS
1) Portability is an important characteristic of this soccer goal and the design and the
material that have been selected are intended to enhance the feature.
Consequently, this goal may tip over under certain load conditions, such as
high winds or climbing onto the framework. It is highly recommended that
this unit be properly anchored for improved stability. If there are any
questions please contact Customer Service at (800) 243-0533.
2) The size and weight of this portable soccer goal dictates that at least four
persons are required when carrying this unit. For best results, tip the goal onto
it’s face. Position one person at each of the four corners and lift carefully. If the
wheel kit option is used, only two persons are needed to move the goal.
