Rev- 2/17/2011 Page 5 of 12
IMPORTANT NOTICE:
1) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING
HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR
MISSING HARDWARE IMMEDIATELY.
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE
HAZARDOUS.
3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE
HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT,
CONTACT YOUR DEALER OR JAYPRO SPORTS.
*** ASSEMBLY INSTRUCTIONS REQUIRES 3 PEOPLE ***
TOOLS REQUIRED:
(1) 9/16” Socket Wrench and Box Wrench
(1) 7/32” Allen Wrench
(1) Rubber Mallet
(1) Step Ladder
•
Unpack all parts and check against parts list to ensure that all have been
included.
•
Inspect all parts for damage. Report any damages to the trucking company.
Front Goal Face Assembly:
1. Insert both corner plate fittings (6) into soccer crossbar (2).
2. Install hardware loosely, as shown.
3. Slide both 9-5/8” long nut & spacer block (11 & 12) into the soccer
upright (1) channel and insert uprights (1) into both corner plate fittings
(6).
4. Install hardware loosely.
5. Attach both European left & right backstays (7 & 8) on corner plate
fittings as shown on uprights (1).
6. Install hardware loosely, as shown.
7. Insert bottom corner fittings (5) into both uprights (1). Slide base (3)
onto bottom corner fittings (5).
8. Install hardware loosely, as shown.
9. Align parts and tighten hardware.
