JAYPRO SPORTS
CLUB GOAL REAR CROSSBAR KIT
CSG-824RX/CSG-721RX/CSG-618RX
LIST OF MATERIALS
PIECE NO. PART NO. DESCRIPTION QTY.
1A SGP760RX2 REAR CROSSBAR 24’ 2
1B CSG721RX1 REAR CROSSBAR 21’ 2
1C CSG618RX1 REAR CROSSBAR 18’-6” 2
2 SF5015 2” CLAMP-ON TEE FITTING 4
3 HS283 HEX HEAD BOLT 5/16”-18 x 3” 4
4 HW2049 FLAT WASHER 5/16” 8
5 HN261 LOCK NUT 5/16”-18 4
6 -------- HEX HEAD BOLT 3/8”-16 x 2 ½” 4
7 HM254 HEX WRENCH 5/16” 1
ASSEMBLY INSTRUCTIONS
1) FIRST, ASSEMBLE BOTH TEE FITTINGS ONTO THE CROSSBAR (1).
INSERT HEX HEAD BOLT (2), WITH FLAT WASHERS (4), THROUGH THE
CROSSBAR AND TEE FITTING, THEN TIGHTEN FIRMLY WITH LOCK
NUT (5). TIGHTEN END SET SCREW AND SIDE SET SCREW USING THE
HEX WRENCH (7) PROVIDED.
2) AFTER BOTH TEE FITTINGS ARE ASSEMBLED, REMOVE THE 3/8”
BOLTS AND LAY THE BACKSTAYS INTO THE FITTINGS AS
ILLUSTRATED.
3) FINALLY, INSERT THE 3/8” BOLTS AND SNUGLY TIGHTEN DOWN.
