Jaypro Sports SFGA-6 User Manual
Page 2
Rev -, 2/10/2011
Page 2 of 3
JAYPRO SPORTS
SOCCER / FOOTBALL GOAL ANCHOR KITS
IMPORTANT NOTICE:
1. BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING
HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR
MISSING HARDWARE IMMEDIATELY.
2. SECURELY TIGHTEN ALL NUTS AND BOLTS.
3. USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE
HAZARDOUS.
4. ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE
HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR
REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS.
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED:
(1) Socket or Box Wrench Set
(1) Scissors
Unpack all parts and check against parts list to ensure that all have been included.
Identify all frame components and lay them out on a flat dry surface.
Inspect all parts for damage. Report any damages to the trucking company.
ITEM
DESCRIPTION
SFGA-6
SFGA-5
SFGA-4
1
2” x 4” LAMAN CLAMP
1
1
1
2
PIPE CLAMP FOR 6-5/8” GOOSENECK
1
N/A
N/A
3
PIPE CLAMP FOR 5-9/16” GOOSENECK
N/A
1
N/A
4
PIPE CLAMP FOR 4-1/2” GOOSENECK
N/A
N/A
1
5
6-5/8” U-BOLT, ZP
1
N/A
N/A
6
5-9/16” U-BOLT, ZP
N/A
1
N/A
7
4-1/2” U-BOLT, ZP
N/A
N/A
1
8
1/2”-13 NYLON FLANGE LOCK NUT, ZP
2
2
2
9
1/2”-13 THICK NYLON LOCK NUT, ZP
2
2
2
10
1/2” SAE FLAT WASHER, ZP
2
2
2
11
SELF-GRIP VINYL EDGE TRIM
1
1
1
12
BUNDLE WARP
1
1
1
QTY: EACH UNIT
