JAYPRO SPORTS
15’ PLAYER’S BENCH WITH BACK REST, PB-20SM
LIST OF MATERIALS
PIECE NO. PART
NO. DESCRIPTION QTY.
1 AR5044 Bolt Clip With Slot 12
2 AR5045 End Cap 4
3 HB5030 Carriage Bolt 5/16”-18 X 3” 12
4 EP0018 2” x 2” End Plug 6
5 HS5035 #8 Pan Head Screw x ½” 8
6 HN5046 5/16” Flange Nut 12
7 AR5043 Seat Plank x 15’ 2
8 PBSM-L Bench Leg 3
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED: Phillips Screwdriver Bit With Electric Drill (1),
½” Socket Wrench Or Adjustable Wrench (1)
1) Slip the end caps (2) snugly onto each end of the plank (7). Using the electric drill,
assemble a self-drilling screw (5) through the cap and into the flange of the plank.
Two screws are required per end cap.
2) For easiest assembly, position seat plank (7) on a level raised surface such as a desk
top, bleacher seat or work bench. Place the carriage bolt (3) and bolt clips (1)
approximately into place within the slots of the plank. Note that the legs should be no
more than 8” from the plank edge.
3) Position the legs as shown and loosely assemble the hardware illustrated in detail ‘A-
A’. Do not fully tighten the hardware at this time.
4) Stand the unit upright and assemble the backrest plank (7) as illustrated. Level the
bench and make sure the legs are adequately spaced apart. Tighten all fasteners fully.
5) Locate assembled bench into position and carefully mark the hole locations for each
mounting plate. Use fasteners (minimum 3/8” diameter) appropriate for your surface
material. Follow manufacturer’s instructions fully.
