Jaypro Sports BLCH-321 User Manual
Page 2
REV-A, 4/10
JAYPRO SPORTS
3 ROW, ALUMINUM BLEACHER WITH GALVANIZED LEG PARTS LIST
ITEM PART
#
DESCRIPTION
BLCH-3
BLCH-321
1
BLCH-3L
3-ROW GALVANIZED STEEL BLEACHER LEG
3
4
2 BLCHX-76
BLEACHER X-BRACE, 3rd ROW (BLCH-3X / BLCH-321X)
4 6
3
AR5043
9-1/2" x 1-1/2" x 15' STADIUM PLANK
5
N/A
4
AR5052
9-1/2" x 1-1/2" x 21' STADIUM PLANK
N/A
5
5
HB5054
5/16"-18 x 1-1/4" CARRIAGE BOLT, ZP
30
40
6
HN5046
5/16"-18 FLANGE NUT, ZP
30
40
7 AR5044 5/16"
BOLT
CLIP
30
40
8
HS5035
#8 x 1/2" PAN HEAD PHILIP SCREW SELF DRILL, ZP
20
20
9
AR5045A
9-1/2" ALUMINUM SEAT PLANK END CAP
10
10
10
HW2047
3/8" SAE FLAT WASHER, ZP
6
8
11
HN5042
3/8"-16 FLANGE HEX NUT, ZP
6
8
12
HS288
3/8"-16 x 1-1/2" HEX HD CAP SCREW, ZP
6
8
Kit # →
BLCH-3K BLCH-321K
Box # →
1
1
IMPORTANT NOTICE:
1) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING
HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR
MISSING HARDWARE IMMEDIATELY.
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE
HAZARDOUS.
3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE
HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR
REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS.
