REV-A, 4/10
JAYPRO SPORTS
4 ROW, 15 FT ALUMINUM BLEACHER PARTS LIST
ITEM PART # DESCRIPTION BLCH-4AL BLCH-4TRG BLDP-4AL BLDP-4TRG
1 BLAL-4RL 4 ROW LEG FRAME – ALUMINUM 3 3 3 3
2 BLALX-77 1/4" x 1 1/4" FLAT X-BARS (BLAL-4RX) 4 4 4 4
3 AR5043 9 1/2" x 1 1/2" x 15' STADIUM PLANK 7 7 10 10
4 AR5044 5/16" BOLT CLIP 42 42 60 60
5 AR5045A 9 1/2" SEAT PLANK END CAP 14 14 20 20
6 HS5035 #8 x 1/2" PHILIP SCREW, ZP 28 28 40 40
7 HS287 3/8"-16 x 1 1/4" HX HD SCREW, ZP 8 23 8 23
8 HB5054 5/16"-18 x 1 1/4" CARRIAGE BOLT, ZP 42 42 60 60
9 HN5046 5/16"-18" FLANGE NUT 42 42 60 60
10 HN5042 3/8"-16 FLANGE NUT, ZP 8 23 8 23
11 CS0011 CASTER WHEEL N/A 6 N/A 6
12 RR5005 RUBBER BUMPER N/A 15 N/A 15
13 HN5038 1/2"-13 FLANGE NUT, ZP N/A 12 N/A 12
14 HW2050 3/8" FLAT WASHER, ZP 8 23 8 23
Kit # → BLCH-4K BLTR-415K BLDP-4K BLDP-415TRK
Box # → 1 1 1 1
IMPORTANT NOTICE:
1) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING
HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR
MISSING HARDWARE IMMEDIATELY.
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE
HAZARDOUS.
3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE
HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR
REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS.
