Jaypro Sports BLDP-321TRG User Manual
Page 2
REV-A, 4/10
JAYPRO SPORTS
3 ROW, 21 FT ALUMINUM BLEACHER PARTS LIST
ITEM PART
#
DESCRIPTION
BLCH-
321AL
BLCH-
321TRG
BLDP-
321AL
BLDP-
321TRG
1
BLAL-3RL
ALUMINUM
3-ROW
BLEACHER
LEG
4 4 4 4
2
BLAL-3RX-1
1/4" x 1-1/4" FLAT X-BARS (BLAL-321RX)
6
6
6
6
3
AR5052
9-1/2" x 1-1/2" x 21' STADIUM PLANK
5
5
7
7
4
CS0011
1/2"-13 x 1-1/2" THREAD x 4" DIA. CASTER WHEEL
N/A
4
N/A
4
5
RR5005 RUBBER
BUMPER
N/A 16 N/A 16
6
HN5038 1/2"-13
FLANGE
NUT
11 15 11 15
7
HW2050
3/8" FLAT WASHER, ZP
N/A
16
N/A
16
8
HS287
3/8"-16 x 1-1/4" HEX HEAD CAP SCREW, ZP
N/A
16
N/A
16
9
HN5042 3/8"-16
FLANGE
HEX
NUT,
ZP
N/A 16 N/A 16
10
HB5054
5/16"-18 x 1-1/4" CARRIAGE BOLT, ZP
40
40
56
56
11
HN5046
5/16"-18 FLANGE NUT, ZP
40
40
56
56
12
AR5044 5/16"
BOLT
CLIP
40 40 56 56
13
HS5035
#8 x 1/2" PAN HEAD PHILIP SCREW SELF DRILL, ZP
20
20
28
28
14
AR5045A
9-1/2" ALUMINUM SEAT PLANK END CAP
10
10
14
14
15
HW2044 1/2"
FLAT
WASHER
11 7 11 7
16
HS2884
1/2"-13 x 1-1/2" HX HD CAP SC, ZP
11
7
11
7
Kit # →
BLCH-
321K
BLTR-
321RK
BLDP-
321K
BLDP-
321RK
Box # →
1 1 1 1
IMPORTANT NOTICE:
1) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING
HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR
MISSING HARDWARE IMMEDIATELY.
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE
HAZARDOUS.
3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE
HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR
REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS.
