JAYPRO SPORTS
3 ROW, 7 ½ FT ALUMINUM TIP n’ ROLL BLEACHER PARTS LIST
ITEM PART
#
DESCRIPTION
BLCH-375TRG BLDP-375TRG
1
BLAL-3RL
ALUMINUM 3-ROW BLEACHER LEG
2
2
2
BLAL-3RX-1 1/4" x 1-1/4" FLAT X-BARS (BLAL-375RX)
2
2
3
AR5046
9-1/2" x 1-1/2" X 7'-6" STADIUM PLANK
5
7
4
CS0011
1/2"-13 x 1-1/2" THREAD x 4" DIA. CASTER WHEEL
4
4
5 RR5005
RUBBER
BUMPER
8
8
6 HN5038
1/2"-13
FLANGE
NUT
9
9
7
HW2050
3/8" FLAT WASHER, ZP
8
8
8
HS287
3/8"-16 x 1-1/4" HEX HEAD CAP SCREW, ZP
8
8
9
HN5042
3/8"-16 FLANGE HEX NUT, ZP
8
8
10
HB5054
5/16"-18 x 1-1/4" CARRIAGE BOLT, ZP
20
28
11
HN5046
5/16"-18 FLANGE NUT, ZP
20
28
12
AR5044
5/16" BOLT CLIP
20
28
13
HS5035
#8 x 1/2" PAN HEAD PHILIP SCREW SELF DRILL, ZP
20
28
14
AR5045A
9-1/2" ALUMINUM SEAT PLANK END CAP
10
14
15
HW2044
1/2" FLAT WASHER
1
1
16
HS2884
1/2"-13 x 1-1/2" HX HD CAP SC, ZP
1
1
Kit
#
→
BLTR-375RK BDTR-375RK
Box # →
1 1
IMPORTANT NOTICE:
1) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING
HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR
MISSING HARDWARE IMMEDIATELY.
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE
HAZARDOUS.
3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE
HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR
REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS.
