REV-, 4/10
JAYPRO SPORTS
2 ROW, 7 ½ FT ALUMINUM TIP n’ ROLL BLEACHER PARTS LIST
ITEM PART # DESCRIPTION BLCH-275TRG BLDP-275TRG
1 BLAL-2RL ALUMINUM 2-ROW BLEACHER LEG 2 2
2 BLAL-3RX-1 1/4" x 1-1/4" FLAT X-BARS (BLAL-375RX) 2 2
3 AR5046 9-1/2" x 1-1/2" x 7-1/2' STADIUM PLANK 3 4
4 CS0011 1/2"-13 x 1-1/2" THREAD x 4" DIA. CASTER WHEEL 4 4
5 RR5005 RUBBER BUMPER 6 6
6 HN5038 1/2"-13 FLANGE NUT 9 9
7 HW2050 3/8" FLAT WASHER, ZP 6 6
8 HS287 3/8"-16 x 1-1/4" HEX HEAD CAP SCREW, ZP 6 6
9 HN5042 3/8"-16 FLANGE HEX NUT, ZP 6 6
10 HB5054 5/16"-18 x 1-1/4" CARRIAGE BOLT, ZP 12 16
11 HN5046 5/16"-18 FLANGE NUT, ZP 12 16
12 AR5044 5/16" BOLT CLIP 12 16
13 HS5035 #8 x 1/2" PAN HEAD PHILIP SCREW SELF DRILL, ZP 12 16
14 AR5045A 9-1/2" ALUMINUM SEAT PLANK END CAP 6 8
15 HW2044 1/2" FLAT WASHER 1 1
16 HS2884 1/2"-13 x 1-1/2" HX HD CAP SC, ZP 1 1
Kit #
→
BLTR-275RK BLDP-275RK
Box # →
1 1
IMPORTANT NOTICE:
1) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING
HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR
MISSING HARDWARE IMMEDIATELY.
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE
HAZARDOUS.
3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE
HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR
REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS.
