Page 2
Rev-
3/11
Page 2 of 6
IMPORTANT NOTICE:
1) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING
HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR
MISSING HARDWARE IMMEDIATELY.
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE HAZARDOUS.
3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE
HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT,
CONTACT YOUR DEALER OR JAYPRO SPORTS.
*** ASSEMBLY INSTRUCTIONS REQUIRES 3 PEOPLE ***
TOOLS REQUIRED:
(1) Socket Wrench and Box Wrench Set
(1) Drill With 7/16” & 11/32” Bits
(1) Hacksaw / Sawzall
(1) Threadlocker – Recommended (Loctite Blue)
Unpack all parts and check against parts list to ensure that all have been included.
Inspect all parts for damage. Report any damages to the trucking company.
PARTS LIST
ITEM QTY:
DESCRIPTION
PART#
1
4
SHOT CLOCK MOUNTING PLATE
SCKT-A
2
2
SHOT CLOCK STAND
SCKT-B
3
2
1 3/4" x 1 3/4" x 48" PERFORATED TUBE
SCKT-1
4
2
SHOT CLOCK BRACKET
SCKT-2
5
4
SHOT CLOCK BOARD PLATE
SR5428
6
4
3/8" x 4" SQ. U-BOLT W/ HARDWARE
HB5085
7
4
5/16-18 x 1 HEX HEAD CAP SCREW, ZP
HS2650
8
8
3/8-16 x 2 HEX HD CAP SCREW ZP
HS289
9
4
3/8-16 x 3 HEX HEAD CAP SCREW ZP
HS292
10
2
3/8-16 x 2 1/2 HEX HEAD CAP SCREW, ZP
HS291
11
10
3/8"-16 x 1 1/2" HEX HD CAP SCREW ZP
HS288
12
38
3/8" SAE FLAT WASHER, ZP
HW2047
13
32
3/8" MEDIUM SPLIT LOCK WASHER, ZP
HW334
14
8
5/16" FLAT WASHER SAE, ZP
HW2049
15
4
5/16" LOCK WASHER, ZP
HW328
16
4
5/16" HEX NUT, ZP
HN260
17
14
3/8"-16 FINISH HEX NUT, ZP
HN264
18
10
3/8"-16 SLAB BASE TEE NUT, SS
HN5040
19
2
CAP FOR 1-3/4" TUBE
EP0028
