2/25/13 Page 13 of 14
SET-UP AND TRANSPORT
Raising and Lowering the Upper Cage:
NOTE: At least two people are required for the following steps.
Caution: Keep body parts clear of pinch points between pipes and fittings.
1. Two struts are required to raise and support each arch. The raising of each arch
must be done in tandem, with equal pressure and extension.
2. Attach one end of two struts to top front frame horizontal pipe, secure in place
with a quick release pin or locking claw. Space these apart so that one of the
struts is attached at each end of the horizontal frame pipe.
3. Push up and forward on each of the struts attached in the previous step; front
section of frame should be moving easily and without binding while raising struts.
Caution: Watch for any binding of frame and/or netting while doing this, stop
immediately if anything is caught on frame hardware. Take extreme care while
doing these steps to prevent frame and/or net damage.
4. Place bottom end of struts onto next folding frame section, and secure in place
with quick release pins or locking claw.
5. Take two more struts and place inboard of the previous two struts on the second
frame folding section horizontal pipe. Secure using quick release pins or locking
claw.
6. Push up and forward on each of the struts from the previous step; front and
second sections of frame should be moving up and forward easily without binding
while raising struts.
7. Repeat for the next frame section.
8. Attach the final two struts and move the entire upper frame into position. The
entire front of cage may now begin to pull forward due to gravity at this point,
and will come to rest on the ground.
9. Place the bottom clamp onto top pipe of the lower frame, and secure in place with
quick release pins or locking claw. Some effort may be required to seat these last
two fittings in place, depending on net tension and the ground formation in your
assembly working area.
10. To disassemble, or ‘fold’, unit – reverse above steps. Use caution when lowering
the frame sections to avoid injury.
After each use inspect all fittings, hardware, pipes, and net for integrity and tightness.
Any damage or loose hardware may result in unsatisfactory performance or failure,
Contact factory or dealer for replacement parts.
