JAYPRO SPORTS
VIEWING STAND, CVS-10
LIST OF MATERIALS
PIECE NO. PART
NO. DESCRIPTION
QTY.
1
CVS101
FRAME ASSEMBLY-LADDER
1
2
CVS102
SUPPORT
BRACE
2
3
CVS104
CHAIN x 5’
2
4
HB5028
EYEBOLT 3/8”-16 x 3”
4
5
CVS103
PLATFORM PLANK
1
6
AR5045
END CAP
2
7
HS5035
#8 PAN HEAD SCREW x ½”
4
8
RP4076
END PLUG
6
9
HM6206
5/16” x 3” QUICK RELEASE PIN
2
10
AR5044
BOLT CLIP
4
11
HB5030
5/16”-18 x 3” CARRIAGE BOLT
4
12
HN5046
5/16” FLANGE NUT
4
13
HW337
3/8” LOCK WASHER
4
14
HN266
3/8” HEX NUT
4
15
HM5054
SNAP HOOK 5/16”
4
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED: PHILLIPS SCREWDRIVER BIT WITH DRILL (1)
½”
SOCKET
WRENCH
OR
ADJUSTABLE
WRENCH
(1)
9/16”
SOCKET
WRENCH
OR ADJUSTABLE WRENCH (1)
1. Slip end caps (6) onto the platform plank (5) and fasten in place using the self-
drilling #8 x ½” screws (7) as indicated. Per detail ‘a-a’, position support braces
(2) approximately 20” on center and assemble the platform plank (5) using bolt
clips (10), carriage bolt 5/16”-18 x 3” (11) and flange nut 5/16” (12). Square the
support braces and tighten the hardware firmly.
2. Assemble the eyebolts 3/8”-16 x 3” (4) thru the support braces (1 eyebolt facing
left and 1 eyebolt facing right as shown) and secure with lockwashers 3/8” (13)
and hex nuts 3/8” (14). Tighten hardware firmly. Also assemble eyebolts (4) at
the top of the frame assembly as shown on the illustration and tighten firmly.
3. Attach a snap hook 5/16” (15) to each eyebolt (4). Push end plugs (8) into the
open ends of the frame pieces as shown. Attach the two chain supports (3) to the
snap hooks (15). Slip the assembled viewing stand onto one of the two rails and
lock in position with the quick release pins 5/16” x 3” (9). Now raise the platform
so it is level and adjust the chain length in the snap hooks to hold the platform in
position.
IMPORTANT
- Always use the quick release pins (9) to lock the viewing stand to the frame assembly
(1).
- Once the viewing stand is in selected position and the support chain has been properly
adjusted then fully close the snap hook (15).
- The viewing stand can be easily moved to either the left or right side of the batting cage.
There are also two viewing heights 6” apart.
