JAYPRO SPORTS
(4 PANELS, 2 CENTERS, 2 WINGS OVER HANG)
BSP-44-22 PARTS LIST
ITEM # QTY DESCRIPTION
1 5 UPRIGHT FOR PERMANENT BASEBALL BACKSTOP
2 5 1-5/8” DOME CAP
3 2 1-5/8” O.D. x 112” LONG PIPE
4 16 1-5/8” O.D. x 113-1/2” LONG PIPE
5 2 1-5/8” O.D. x 82-1/2” LONG PIPE
6 5 2-1/2" DOME CAP
7 135 5/16” WASHER
8 135 5/16”-18 HEX NUT
9 135 5/16”-18 x 1-1/4” CARRIAGE BOLT
10 10 6' x 9'-8” CHAIN LINK PANEL
11 2 OVER HANG CHAIN LINK PANEL
12 2 60” LONG UPPER SIDE FRAME SUPPORT
13 5 69” LONG LOWER FRAME SUPPORT
14 3 69” LONG UPPER FRAME SUPPORT
15 32 BAND TENSION (SMALL)
16 48 BAND TENSION 2-1/2” ID
17 24 3/16” THICK BAR TENSION
18 21 BRACE BAND (SMALL)
19 34 BRACE BAND 2-1/2” ID
20 40 RAIL ENDS 1-5/8” ID
21 156 RAIL TIE
