JAYPRO SPORTS
(3 PANELS, 1 CENTER)
BSP-30-6 PARTS LIST
ITEM # QTY DESCRIPTION
1 4 UPRIGHT FOR PERMANENT BASEBALL BACKSTOP
2 2 1-5/8” DOME CAP
3 11 1-5/8” O.D. x 113-1/2" LONG PIPE
4 4 2-1/2” DOME CAP
5 72 5/16” WASHER
6 72
5/16”-18 HEX NUT
7 72
5/16”-18 x 1-1/4” CARRIAGE BOLT
8 7 6' x 9'-8” CHAIN LINK PANEL
9 2 69" LONG LOWER FRAME SUPPORT
10 2 69" LONG UPPER FRAME SUPPORT
11 8 BAND TENSION (SMALL)
12 36 BAND TENSION 2-1/2” ID
13 14 3/16'' THICK BAR TENSION
14 6 BRACE BAND (SMALL)
15 22 BRACE BAND 2-1/2” ID
16 22 RAIL ENDS 1-5/8” ID
17 75 RAIL TIE
