The numbers in parentheses indicate the pages where each item is explained.
.
Camera
General Guide
4 2 1 3 5
6 7
[ ]
[ ]
[ ] [ ]
[SET]
bl bk 9 8
bs bt
bm
bo bp bq br
bn
1 Zoom controller
(pages 26, 47, 87, 88)
2 Shutter button (page 25)
3 [ON/OFF] (Power)
(page 23)
4 Flash (page 38)
5 Front lamp (pages 45)
6 Lens
7 Microphone
(pages 51, 99)
8 [AUTO] button (page 25)
9 Back lamp
(pages 23, 26, 38)
bk [0] (Movie) button
(page 50)
bl Connector cover
bm USB/AV port (pages
88, 109, 117, 126)
bn Strap hole (page 2)
bo [SET] button (page 33)
bp [ ] (Delete) button
(page 30)
bq [p] (PLAY) button
(pages 23, 29)
br Control button
([8] [2] [4] [6])
(pages 13, 30, 33, 38,
63)
bs [r] (REC) button
(pages 23, 25)
bt Monitor screen
(pages 11, 13)
Back
ck Battery/memory card slots (pages 17, 21, 153, 154)
cl Tripod hole
Use this hole when attaching to a tripod.
cm Speaker
Front
ck cl cm
Bottom
