Computer Tech Link CTL 5xn - Manual (Page 15)

10
Tilt /Swivel Range Tilt : 5 ¡£ forward, 10 ¡£ backward
Swivel : ¡ 45 ¡£ leftward, rightward
Dimension 368(W) ¡¿ 394(D) ¡¿ 382(H)mm
(set with stand)
Weight (net/Gross) 27.6/31.4 lbs
12.5/14.2Kg
Operating Environment
Temperature : 10~4˚C/50~104˚F
Relative Humidity : 8~80%
Storage Environment
Temperature : -20~45˚C/-68~113˚F
Relative Humidity : 5~90%
FACTORY PRESET TIMINGS
Mode
Resolution
H.Freq (KHz) V. Freq (Hz) Remark
(dots ¡ ¡¿ ¿ lines)
VGA 720 ¡¿ 400 31.5 70 Non-interlaced
VGA 640 ¡¿ 480 31.5 60 Non-interlaced
VESA VGA 75 640 ¡¿ 480 37.5 75 Non-interlaced
VESA 46K 800 ¡¿ 600 46.9 75 Non-interlaced
VESA 1024/60 1024 ¡¿ 768 48.4 60 Non-interlaced
VESA 800x600 @85Hz 800 ¡¿ 600 53.7 85 Non-interlaced
This monitor has stored above-mentioned six timings in factory. You
can save up to 10 modes in the user memory automatically. Please note
that if you save to user memory over ten times, the first mode saved
will be replaced with your eleventh mode.
