Structure, Components, 2 structure – IC Realtime 1.3 Megapixel HD Network IR Dome Camera (ICIPD1300IR) User Manual
Page 9: 1 components
4
2 Structure
2.1 Components
You can refer to the following figure for
multiple-function combination cable
information. See Figure
Figure 2-1 Multiple-function combination cable
Please refer to the following sheet for detailed information.
No.
Port
Name
Connector Note
3
DC12V
DC
12V
power
To connect to DC12V power
supply.
4
LAN
Network
port
Ethernet
To
connect
to
standard
Ethernet.
Component
Component Name
Component 1
Device lens
Component 2
Dome body
