Interceptor Manual
16
Tuning and Navigating through the Front end
The interceptor program has been designed so that the user can navigate using only the
keyboard. To navigate between the setup view and tuning view windows, the user can press the
Tab key.
To navigate through the setup menu the user can press the up and down arrow keys. Once the
user gets to the desired item, the enter key is pressed to select that item. This will display the
corresponding setup dialog box. For the setup pages that contain multiple tabbed pages the user
presses Ctrl – Tab to cycle through the pages. To apply any setup pages the user can press Enter
or click OK.
To adjust the fuel, ignition and boost maps the user can press “F” to jump to the fuel map, “I”
to jump to the ignition map, or “B” to jump to the boost map. This will shift the focus to the text
view in the bottom right corner of the screen.
Once in tuning mode the user has several options for adjusting the maps. To change a single cell
at a time the user simply uses the arrow keys to go to the desired cell, and types in the desired
number. To select multiple values the user presses the Ctrl key and the up and down arrows to
increase the selected cell range. To change these values to a desired value the user presses the V
key and this changes all selected values to the entered value. A summary of the keystrokes is
shown below:
Key Function
Ctrl - C Copy selected values
Ctrl - V Paste copied values
Up arrow key Move selected value up the RPM range
Down arrow key Move the selected value down the RPM range
Right arrow key Move the selected value up through the load index range.
Left arrow key Move the selected value down through the load index range.
Ctrl - Up arrow key Increases the no of selected points up the RPM range.
Ctrl - Down arrow key Increases the no of selected points down the RPM range.
Ctrl - Right arrow key Increases the no of selected points up through the load range.
Ctrl - Left arrow key Increases the no of selected points
L Linearise the selected values
Space bar Take selected values to the current engine position
Ctrl - Space bar This centers the selected values to one point.
V This allows the user to enter a specified value for the selected
values
Enter This applies the changes
T This turns the trace function on and off
