FILTER REpLACEMENT

To maintain the performance of the air cleaner, it is recommended that the filter be replaced about

every 6 months. The replacement requirements will vary depending on usage and environmental

conditions.

CHANGE FILTER INDICATOR

The green power light on the air cleaner will turn red and flash continuously indicating that it is time
to replace the filter. Replace the filter according to the directions then press the UV/HEPA Reset
Button and hold for 3 seconds to restart the system. The light will turn back to green. Depending on
usage, filter will last approximately 6 months.

E-8

E-9

CLEANING & MAINTENANCE

e. Reattach the Rear Cover of the unit and

securely latch into place.

Clean Air Delivery Rate

From air cleaner to air cleaner, compare the CADR numbers. First look at suggested room size. Then refer

to the Clean Air Delivery Rate (CADR) numbers. The higher the number, the faster the unit filters the air.

This air cleaner is suggested for use in a single, closed room up to 183 square feet.

Higher CADR rates provide improved performance in all room sizes. Portable air cleaners will be much

more effective in rooms when all the doors and windows are closed.

TObACCO SMOkE: 118+

This value represents performance that can be expected within the first 72 hours of operation. Subsequent

use may vary with use.
Tested per ANSI/AHAM AC-1 National Standard

NOTE

: Do NOT stick any foreign objects or your fingers inside of the unit.

CAUTION

: Do NOT use gasoline, benzine, thinner, harsh cleaners, etc. on and/or in

the unit while cleaning as they will damage the product.
NEVER use alcohol or other solvents.

What is CADR?

CADR stands for “Clean Air Delivery Rate,” which indicates the volume of filtered air delivered by

an air purifier. CADR ratings show the effectiveness of how efficient the air purifier is at capturing

fine particules from things like tobacco smoke and plant pollens from the room.

INSTALLING & REMOVING UV-C bULb

1. Remove the Rear Cover

of the unit by pushing

Lock & Release Button.

2. After removing the Rear

Cover from the unit, remove

the Combination Filter.

3. After removing the Combination

Filter, use a Philips head

screwdriver to remove two (2)

screws and detach the UV-C

Metal Shield.

4. The UV-C Bulb is removed

by carefully grasping the

bulb with a clean cloth or

tissue and pulling the bulb

straight out of the unit.

5. The UV-C Bulb is reinstalled by sliding it, horizontally, back into the slots at the top of the unit.
6. Push and hold UV/HEPA Reset Button for 3 seconds to reset UV Bulb Change Indicator.

bulb is NOT visible until

the UV-C METAL SHIELD

has been removed.

REpLACEMENT bULb: Lb4000

AVAILAbLE AT 866.603.5900 OR WWW.GUARDIANTECHNOLOGIES.COM

pULL UV-C bULb

STRAIGHT OUT OF UNIT

CHANGE bULb INDICATOR

The UV-C light on the front of the air cleaner will turn red when it is time to replace the bulb.
Replace the bulb according to the directions then press the UV/HEPA Reset Button and hold for
3 seconds to restart the system. The light should remain a constant blue.

REpLACE bULb
